Model:GN-40
Product Description
The GN-40 is a multi-functional reinforced ground spike base designed with an L-shaped bracket, providing superior strength and flexibility.
The top section supports direct installation of an M-type (SO-239) female connector, or can use an M16 hole-to-3/8” thread adapter for compatibility with a wide range of antennas.
Compared to the GN-25Q, the GN-40 delivers greater stability and broader compatibility, making it ideal for 5.2 m carbon fiber telescopic poles and large HF antennas.
This ground spike is especially suited for long-term outdoor installations, portable base stations, and high-power operation.
In addition, the GN-40 can be paired with our dedicated connectors, including:
JS-SO-239-F-STUD-3824
JS-N-F-C-L24 (N-F Crimp Type)
JS-SO-239-L25 (SO-239 Long Type)
The GN-40 also supports direct mounting of an L-type M-type female connector, offering even more flexibility and ease of use.
Product Specifications
Size: L60 × H70 × W395 mm
Weight: approx. 380 g
Product Advantages
Multi-Functional Interface: Supports M-type (SO-239) connectors, or 3/8” threaded antennas via adapter.
Dedicated Connector Options: Compatible with JS-SO-239-F-STUD-3824, JS-N-F-C-L24, and JS-SO-239-L25.
Dedicated Connector Options: Compatible with JS-SO-239-F-STUD-3824, JS-N-F-C-L24, and JS-SO-239-L25.
Reinforced Design: Strong and durable, ideal for heavy-duty and long-duration antenna setups.
High Compatibility: Works with multiple antenna types, connectors, and modular accessories.
Excellent Stability: Secure ground insertion, perfect for 5.2 m poles and large HF antennas. Versatile Applications: Outdoor base stations, seaside installations, field experiments, and high-power operations.
“Also available in white.”
